CODE PREFIX: GPS709
Concrete Spacer – Cone with Wire
A tapered precast concrete cone spacer with two wire tails that tie directly onto the reinforcement, holding the specified concrete cover at wall and slab penetration points. Supplied in 5 cover sizes from 30mm to 50mm, each rated to 200kg.
APPLICATIONS
Where it's used
Wire-Tied Cover Control
The two wire tails tie the spacer directly to the reinforcement, keeping it seated at the specified cover through placement and vibration.
Wall & Slab Face Spacing
The tapered cone profile suits vertical wall faces and slab soffits where a flat-based spacer isn't practical.
Consistent Load Rating
All 5 cover sizes carry the same 200kg rating, simplifying specification across different cover depths on the same project.
Material
Concrete with Galvanized Steel Wire Ties
Load Range
200 kg
Safety Factor
N/A
SPECIFICATIONS
Available Sizes
| Item | Code | Cover (mm) | Load strength (kg) |
|---|---|---|---|
| 30 | GPS709300 | 30 | 200 |
| 30-1 | GPS709301 | 30 | 200 |
| 35 | GPS709350 | 35 | 200 |
| 40 | GPS709400 | 40 | 200 |
| 50 | GPS709500 | 50 | 200 |
- Other different sizes are available upon request.
- Two separate codes exist at the 30mm cover (GPS709300 and GPS709301) - preserved as two distinct source rows, as shown in the source table.
