CODE PREFIX: GPS1002
Double Head Lifting Anchor
A cast-in lifting anchor with a flat round head and ribbed shank, embedded flush in the concrete surface to provide a secure, low-profile lifting point. Available in 1.3-5.0 t rated loads with multiple shank lengths to suit different panel thicknesses.
APPLICATIONS
Where it's used
Precast Wall Panel Lifting
Cast into architectural and structural wall panels to provide a flush, load-rated lifting point for demoulding and crane handling.
Floor & Roof Slab Handling
Embedded in precast floor and roof slabs for safe transfer from the casting bed to storage and delivery.
Tilt-Up & Site Erection
Used with a matching lifting clutch to tilt, lift and position precast elements during on-site erection.
Material
Forged Carbon Steel
Load Range
1.3 – 5.0 tons
Safety Factor
3:1
SPECIFICATIONS
Available Sizes
| Rated Load (Tons) | Code | D (mm) | D1 (mm) | D2 (mm) | Popular Length (mm) |
|---|---|---|---|---|---|
| 1.3 | GPS1002013 | 10 | 19 | 25 | 50, 55, 65, 85, 100, 120 |
| 2.5 | GPS1002025 | 14 | 26 | 35 | 65, 85, 110, 120, 140, 170 |
| 5.0 | GPS1002050 | 20 | 36 | 50 | 95, 120, 140, 170, 180, 210 |
- Other different Length and load capacity are available upon request.
- Stainless Steel 304 (A2) / 316 (A4) available upon request.
- Surface finish options: Black (B) / Zinc Plated (Z.P) / Hot Dipped Galvanized (H.D.G).
