CODE PREFIX: GPS100917
Easy Lift Foot Anchor
An imperial-sized foot anchor rated by safe working load against the host panel's thickness, suited to tilt-up and sandwich wall panel production.
APPLICATIONS
Where it's used
Tilt-Up Wall Panel Production
Sized and rated specifically for common tilt-up panel thicknesses.
Insulated Sandwich Panel Lifting
Suited to thinner precast sandwich panels where embedment depth is limited.
North American Precast Projects
Imperial sizing and SWL-by-thickness rating match common US/Canadian precast specification practice.
Material
Forged Carbon Steel
Load Range
4,100 – 11,000 lbs SWL
Safety Factor
4:1
SPECIFICATIONS
Available Sizes
| Code | Length (inch) | SWL @4" (LBS) | SWL @5" (LBS) | SWL @6" (LBS) | SWL @7" (LBS) |
|---|---|---|---|---|---|
| GPS100917412 | 4-1/2 | 4100 | 4600 | 5000 | 5800 |
| GPS100917512 | 5-1/2 | 5600 | 6300 | 7100 | 7800 |
| GPS100917718 | 7-1/8 | 7800 | 8800 | 9800 | 11000 |
- Rated by SWL (lbs) at panel thickness 4"/5"/6"/7", not by tonnage.
- Surface finish options: Black (B) / Zinc Plated (Z.P) / Hot Dipped Galvanized (H.D.G).
